| Item | Descriptions | |
| General | Principle | Immunofluorescent, quantitative |
| Light source | Laser diode 365 ± 5nm | |
| Calibration | Magnetic card auto calibration | |
| LIS | Support LIS | |
| Language | English/Chinese | |
| Test | Incubation time | 3-15min |
| Measurement time | 15sec | |
| Sample volume | 100 μL | |
| Test mode | Standard and rapid mode | |
| Specifications | Input | 5 nch touch screen |
| Output | Internal thermal printer, support auto print, manual print | |
| Printer paper | 57×35mm | |
| Interface | RS232 port | |
| Result storage | 50,000 results | |
| Dimension | 400(L)×400(W)×290(H) mm | |
| Net weight | 4KG | |
| Others | Work temperature | 15-35°C |
| Power requirement | 100~240 AC, 50/60Hz | |
| Power | ≤50VA | |
| Relative humidity | ≤93﹪ | |
| Atmospheric pressure | 70.0kPa-106.0kPa | |
