Ø Multi-position adjustment, using high-performance imported silent push rod motor, easily adjust the backrest, legrest, footrest, one-button CPR, one-button reset.
Ø The buttons of hand control are simple, easy to operate.
Ø International brand silent 24V dc push rod motor, work stably, safe and reliable.
Ø Long - term continuous working system.
Ø 10 years of life design, reduce the cost of maintenance and replacement.
Ø Ultra-low energy consumption, using less than 0.12 degrees per day.
Ø The chair cushion is made of high-density sponge, the elasticity is moderate, sitting and lying for a long time will not cause postural strain; PVC leather is durable, luxurious and comfortable.
Specification
|
Model |
YSHB-CD380S |
|
Total Length |
2040 mm±20mm |
|
Seat Width |
760 mm±20mm |
|
Backrest&Leg length |
1100 mm±20mm |
|
Seat length |
680mm±20mm |
|
Seat height |
580~820mm±20mm |
|
Height of guardrail and seat |
180mm±20mm |
|
Chassis Dimension |
1380mm×600mm±20mm |
|
Castor |
4xφ125mm castors with central brakes |
|
Pillow |
400 mm×230 mm×80 mm±20mm |
|
Safe Maximum Load |
240 KGS |
|
Weight |
110 KGS±3KGS |
|
Backrest Adjustment |
(-12° ~ 70°)±5° |
|
Legrest Adjustment |
(-35° ~ 12°)±5° |
|
Leather |
PVC leather |
|
Cushion |
Sponge |
|
Frame |
Q235 steel |
|
Power Supply |
AC100V-240V 50/60Hz |
|
Input Power |
180~220W |
|
Motor |
3 |
