Basic Parameters |
|
|
Screen |
4.3 inch LCD color touch screen |
|
Infusion Mode |
2/3ml, 5ml, 10ml, 20ml,30ml,50/60ml Open system, automatic recognition of syring brands and sizes after calibration |
|
Accuracy |
士5% |
|
Flow Rate Range |
0.01-2000ml/h(increment 0.01m/h) |
|
VTBI |
0-9999ml |
|
KVO |
0.01-5ml/h adjustable |
|
Bolus Rate |
0.1-2000ml/h(automatic & manual bolus available) |
|
Occlusion Level |
4 levels selectable (optional 12 levels) |
|
Interface |
Type C |
|
Wireless |
Wifi (optional) |
|
Alarm Type |
VTBI Infused, Pressure high, Check upstream, Battery empty, KVO finished, Door Open, Air bubble, VTBI near end, Battery near |
|
Special Features |
|
|
Titration |
Change flow rate without stopping infusion |
|
Last Therapy |
Last therapies can be stored and used for rapid infusion |
|
Drug Library |
No less than 30 drugs |
|
Anti-Bolus |
Automatic drop line pressure to reduce bolus impact after occlusion |
|
Purge |
Remove the air bubble |
|
Screen Lock |
Avoid misoperation |
|
Standby Mode |
Standby time 00-99h59m adjustable |
|
Relay Mode |
Different pumps work in sequence on infusion workstation (optional) |
|
Micro Mode |
Limit the max infusion rate to double ensure patient safety |
|
DPS |
Real-time pressure display in graphically and numerically |
|
Bubble Detector |
Adjustable |
|
Brightness |
Adjustable |
|
Alarm Volume |
Adjustable |
|
History Record |
More than 5000 entries |
|
Power Source |
|
|
AC Power |
100-240V AC, 50/60HZ |
|
External DC Power |
12V |
|
|
Lithium Polymer battery 11.1V 2600mAh |
|
More than 12 hours operating time @5ml/h |
|
|
Less than 5 hours for fully charged |
|
|
Others |
|
|
Classification |
Class I, CF |
|
Waterproof |
IP24 |
|
Dimension |
280(L)*90(W)123(H) |
|
Weight |
Approx. 1.7kg |
