Features:
1. Four work modes: CPAP,S,T,S/T,APCV.
2. APCV mode: Assist pressure control ventilation
3. Dynamically monitor the treatment effect
4. Real-time alarm in case of failure
5. Light weight: 2.0kg
Scope of application:
Assistant therapy of respiratory disease,PHD(Pulmonary heart disease),COPD(chronic obstructive pulmonary disease),Motor neurons.
|
Difference |
YSME-B30P |
|
Screen |
3.5 Inch color TFT |
|
Work mode |
CPAP,S/T,S,T,APCV |
|
Inspiration Pressure |
4-30cmH2O |
|
Inspiration sensitivity |
Auto,1-6 level |
|
Expiration Pressure |
4-25cmH2O |
|
Inspiration sensitivity |
Auto,1-6 level |
|
VAF function |
Yes, Tidal Volume 50~2000ml |
|
Accuracy |
±0.5cmH20 |
|
Belex |
1-3 level (2-4cm H2O), makes the expiration more comfortable |
|
Ramp |
0-60min |
|
Islop |
1-6 Level |
|
BPM |
3-40bpm |
|
Inspiration time |
0.5-4.0s |
|
Noise |
<30dB |
|
Auto on/off |
Auto off while tube/mask off, Auto on when it detects breath |
|
Leakage compensation |
Yes |
|
Altitude compensation |
Yes |
|
SPO2 |
Yes |
|
Humidifier |
0-5 level,water chamber separable |
|
Parameter monitor |
Flow/Press/BPM/VT/MV/LK/InspT/SpO2(Optional)/PR(Optional) |
|
Realtime Alarm |
Power failure/Low voltage/Airway Block/Low MV/High Leakage/humidifier failure/TF card full/High Pressure/Low Pressure/Replace Filter |
|
Data download |
TF Card 8G |
|
Self-diagnostic questionnaire(Epworth) |
Yes, makes patient understand the potential breathing apnoea by himself. |
|
Net Weight/size |
2.2kg, 280*200*112mm(Host+humidifier) |
|
Gross Weight/size |
4.6KG,375*290*235mm |
|
Warranty |
2 years |
