| Observation |
Video Signal Outputs |
Y/C, DVI, AV |
| Image Enhancement |
Profile enhance, 0-3 steps |
| Brightness Adjustment |
± 50 steps |
| Iris |
Average, Peak |
| Agc |
Electronic emphasis on mucosal morphology or outline to enhance the sharpeness of the endoscopic image. |
| W.B. |
Press the switch W.B. to achieve the white balance adjustment |
| Photo/Video |
HD Images/ SD video can be saved |
| Freeze/Black |
HD Image can be frozen, saved and reviewed |
| Power |
Voltage |
˜110V/220V AC (±10%) |
| Frequency |
50Hz/60Hz |
| Air Pump |
Air Flow |
≥ 5L/min |
| Air Pressure |
30-80kPa |
| Lighting |
Bulb |
LED |
| Color Temperature |
≥5500k |
|
