| Performance |
| Leads |
9/12 leads simultaneous acquisition |
| Sampling Rate |
16000Hz/channel/secong |
| A/D Resolution |
24bits |
| HR Range |
30~300bpm |
| Time constant |
≥ 3.2s |
| Polarizing Voltage |
±600mV |
| Input impedance |
>50MΩ |
| Frequency Response |
0.01~300Hz |
| Noise leve |
≤12.5µVp-p |
| DFT Filter |
0.01/0.05/0.32/0.67Hz |
| EMG Filter /Low Pass |
25/35/45/75/100/150/270/300Hz |
| Pacemaker Detection |
Amplitude:±750uV ~±700mv,Width 50 us ~2.0 ms Sampling Frequency :16000Hz |
| LCD Display |
10.1inch TFT color LCD (1024*600) with toch screen) |
| Power Supply |
AC input with external power adaptor of 100~240V,50/60Hz rechargeable Lithium battery (4400mAH) supporting 400 exams. |
| Recording Speed |
5/6.25, 10/12.5/25/50mm/s |
| Recording Paper |
Z-fold 210×295mm×100sheets Roller type 210mm×20/30mm
|
